Brand New Massey Ferguson MF-360 2WD 60hp tractors for sale at a discounted price. We offer export-quality Massey Ferguson tractor models (50hp To 85hp) from Pakistan to Ghana.
Engine Power at 2,250 rpm> | 60 (B.S) hp |
Torque at 1,350 rpm | 212 Nm |
PTO Power at Rated | 48 hp |
Engine Speed | |
*Certified at BS AU 141a |
Voltage | 12V, Negative Earth |
Battery | 118 Ah |
Starter | 2.2 kW |
Alternator | 32 Amp |
Type | Sliding Spur |
Number of Gears | 8 Forward, 2 Reverse |
Road Speed at 2,250 | Engine RPM with 14.9/13x28 rear tyres |
Gear | Speed (km/hr) |
Forward 1 (First Low) | 2.6 |
Forward 2 | 3.8 |
Forward 3 | 5.2 |
Forward 4 | 7.0 |
Forward 5 (First High) | 10.4 |
Forward 6 | 15.2 |
Forward 7 | 20.8 |
Forward 8 | 28.0 |
Reverse 1 (Low) | 3.5 |
Reverse 2 (High) | 14.1 |
Functions | Draft Control, Position Control Response Control, Constant Pumping |
Pump Type | Reciprocating, Ferguson Pump |
Oil Flow | 16.0 ltr/min |
Pressure | 21 Mpa at normal operating temperature |
Lift Capacity with Lower | 2,145 kg |
Links Horizontal | |
Lower Links | With Cat. I & II Interchangeable Balls |
Axle Type | Straddle with apicyclic redution unit |
Brake Type | Oil immersed, Multi-disc |
Brake Pedal | Pendant |
Differential Lock | Mechanical |
Brake Actuation | Mechanical |
Parking Brake | Hand Lever Operated |
Front | 7.50 - 16 (6PR) |
Rear | 14.9 / 13 - 28 (6PR) |
Type | Dual |
Diameter | 305 x 254 mm |
Type | Box Section, Adjustable |
Type | Hydrostatic |
Front Axle | 1,275 -1, 884 mm |
Rear Axle | 1,438 -2, 124 mm |
Make / Type | Diesel /T 3.1524 |
No. of Cylinders | 3 |
Injection | Direct |
Bore | 91.4mm |
Stroke | 127.0mm |
Capacity (litres) | 2.5L |
Compression Ratio | 16.5:1 |
Starting Aid | Thermostart |
Throttle Control | Hand and Feet |
Cooling | Water |
Air Cleaner Type | Oil Bath |
Air Pre-Cleaner | Over Bonnet, Air Swirl |
Fuel Filter | Dual, High Capacity |
Exhaust | Vertical Muffler under bonnet |
Oil Cooler | Water Cooled |
Type | Live |
Engine Speed at 540 pto rpm | 1,789 rpm |
Shaft Diameter | 35mm |
No. of Splines | 6 |
Guages | Technometer, Hourmeter, Fuel Level, Battery Condition & Water Temperature |
Warning Lights | Direction Indicators, Battery Charge, Headlight Main Beam, Low Engine Oil Pressure, Brake Lights & Auxiliary Socket |
Gross Weight | 2,010 kg |
Wheel Base | 2,032 mm |
Overall Length | 3,353 mm |
Overall Width (Min) | 1,890 mm |
Over Exhaust | 2,236 mm |
Over Steering Wheel | 1,499 mm |
With Brakes | 5,876 mm |
Without Brakes | 6,833 mm |
Under Gear Box | 400 mm |
Fuel Tank | 47.5 L |
Engine Pump | 6.8 L |
Cooling System | 11.7L |
Hydraulic System | 36.0L |
Steering Box | 2.0L |
Oil Bath Air-Cleaner | 0.5 L |
